Wire Connecting Aluminium Crimp Cable Connectors GL -1
Overview
Quick Details
- Model Number:
-
GL series
- Type:
-
lug terminals, : Crimp Terminal
- Place of Origin:
-
Zhejiang, China
- Packaging:
-
White inner box + export carton box
- Description:
-
Copper Connecting Terminals
- Production Name:
-
: GL connecting tube
- Material:
-
:Aluminium
- Operating Temperature:
-
: -40℃ to 100℃
- Standard:
-
: AS4325.1, DIN46235, DIN40500/2F-25
Product Description
|
Model
|
D
|
d
|
L
|
|
|
GT -1-10
|
9
|
5
|
52
|
|
|
GT -1-16
|
10
|
6
|
56
|
|
|
GT -1-25
|
11
|
7
|
62
|
|
|
GT -1-35
|
12
|
8
|
67
|
|
|
GT -1-50
|
15
|
10
|
76
|
|
|
GT -1-70
|
17
|
11
|
87
|
|
|
GT -1-95
|
19
|
13
|
92
|
|
|
GT -1-120
|
21
|
15
|
98
|
|
|
GT -1-150
|
23
|
17
|
108
|
|
|
GT -1-185
|
25
|
19
|
114
|
|
|
GT -1-240
|
28
|
21
|
118
|
|
|
GT -1-300
|
34
|
24
|
135
|
|
Specification
Copper Connecting Tube（passing through）
1.These products are applicable to connect the circular wire and hemicycle-sensor. GL series hole passing connection tube is made of L3 aluminium tube.
Packing & Delivery
CASES PACKAGES
